Chemical processing demands precision fluid control, corrosion resistance, and high-pressure durability to safely manage aggressive chemicals, solvents, and volatile compounds. At Gould Solenoid Valves, we specialize in stainless steel solenoid valves, designed to withstand corrosive fluids, high temperatures, and hazardous operating environments.
Our solenoid valves are engineered for reliability and safety, ensuring leak-proof operation, rapid actuation, and compliance with strict industry standards. With same-day and next-day shipping, we help chemical processing plants avoid downtime and maintain efficiency.
Browse Our Inventory
Chemical processing facilities require reliable, corrosion-resistant solenoid valves to ensure safe and precise control of aggressive media. Gould Solenoid Valves are designed to handle:
Gould Solenoid Valves provide precise control, chemical resistance, and long-term durability in industrial processing, refining, and hazardous material handling applications. Built to withstand corrosive fluids, high-pressure chemical flow, and volatile compounds, our valves ensure leak-proof operation and reliable performance in demanding environments.
Gould's stainless steel series. The K series uses cast CF8M 316 stainless bodies rated to 1000 psi in 1/8" to 2" NPT for air, water, oils and corrosive fluids to 300°F. Where the chemistry attacks anything less than full stainless, the KX series is complete 316 stainless steel for all wetted parts at 5–300 psi. Both are full port and packless.
Both use cast CF8M 316 stainless bodies rated to 1000 psi, but the KX is complete 316 stainless for all wetted parts — 316 stainless bonnet tubes welded to a 316 stainless bonnet, 316 stainless piston and expanders, and a 316 stainless jacketed pilot. The trade-off is pressure: the K series covers 5–1000 psi across its models while the KX is limited to 5–300 psi.
K series and KX series bodies are both cast CF8M 316 stainless rated to 1000 psi. Individual model ratings vary by service: the K-3T is 5–150 psi, the KR-3T and KS-3T are 10–400 psi, and liquid-service-only models go higher. The KX series is capped at 5–300 psi and the high-temperature KX-1 at 5–150 psi. Always specify by model, not by body rating.
Teflon™ (-3T) is the broadest-range option and is standard on the K, K-1, KX and KX-1 stainless series. Ethylene propylene (-3EP) is offered on the K and KX series. Viton® (-3V) and Buna (-3B) are available on the K series for specific chemistries. On the KX and KX-1, only Teflon™ and EP are offered, because the wetted-parts specification limits elastomer choice.
Yes. Adding -2 to the part number supplies an explosion-proof coil housing rated Class 1 Div 2, Class 1 Group D and Class 2 Groups E, F and G — NEMA 7 explosion proof — and the same enclosure also satisfies NEMA 4 watertight/corrosive resistant and NEMA 5 dusttight. The option is available across the Q, Q-1, K, K-1, KX, KX-1, B, D, QD and KD series.
A packing gland is a leak path, and it wears. Every Gould Velvetrol® valve is packless, so Gould reports zero fugitive emissions from the valve stem. In a plant carrying volatile or hazardous chemistry, that removes a maintenance item and a compliance exposure at the same time, and there is no gland to repack over the valve's service life.
Two stainless options. The K-1 series is cast CF8M 316 stainless, 1/8" to 2" NPT, 5–400 psi, rated to 450°F with Class H coils and Teflon™ (-3T) seats, and handles steam at 5–150 or 10–200 psi. The KX-1 series is complete 316 stainless for all wetted parts, 1/8" to 2", 5–150 psi, also rated to 450°F.
Gould Solenoid Valves provides high-performance, chemically resistant solutions for fluid control in chemical processing, refining, and hazardous applications. Whether you need immediate delivery to prevent downtime or custom-engineered solutions, our team is here to help. Contact us today.
