Industrial plumbing, process piping, and fluid handling systems demand precise, durable solenoid valves to ensure efficient flow control, leak-free operation, and system reliability.
At Gould Solenoid Valves, we specialize in American-made, high-performance two-way solenoid valves, trusted by process engineers and facility maintenance professionals to regulate water, air, steam, and process fluids in commercial and industrial environments.
With General Purpose M & Q Series valves, Gould provides consistent performance, corrosion resistance, and fast response times—ensuring optimal system efficiency and minimal maintenance across plumbing and fluid applications.
Browse Our Inventory
In commercial and industrial fluid systems, solenoid valves play a critical role in regulating flow, controlling pressure, preventing water hammer, and ensuring leak-proof operation. Gould Solenoid Valves are engineered to handle:
Gould Solenoid Valves are engineered to provide precise flow control, efficiency, and system protection in a variety of industrial plumbing and fluid handling applications. Built for water, steam, compressed air, and chemicals, our valves ensure leak-proof performance and long-term durability in demanding environments.
For general water and light-oil service, Gould's bronze M series covers 1/8" to 2" NPT at 5–250 psi to 250°F, normally closed, with Buna (-3B) or Viton® (-3V) seats. Where higher pressure, larger size or a normally open valve is needed, the bronze Q series covers 1/8" to 3" at 5–400 psi to 300°F in either configuration. Both are full port and packless.
The smallest is 1/8" NPT, available on the M, M-1, Q, Q-1, K, K-1, KX, KX-1, QD, KD and direct-acting B4-21 and BH-19 series. The largest is 3" NPT on the bronze Q, Q-1 and Q-230 series. Stainless series and the D series stop at 2"; the B series is 1/4", 3/8" and 1/2" only.
Yes. Adding -81 to the part number sets the valve for factory slow close, which reduces water hammer; -84 sets it for quick close. This is on top of the inherent damping of the Velvetrol® internal piston pilot, which Gould's testing shows reduces pressure spikes 81–88% versus a conventional valve — 10 psi against 80 psi in the published comparison.
Use a zero-differential or direct-acting valve. The QD and KD series open at 0 psi in 1/8" to 1" NPT but are rated for only a small maximum differential — 6 psi on water at 1/8" to 1/2", dropping to 1 psi at 1". The direct-acting B4-21 handles 0–200 psi on air, 0–100 psi on water and 0–75 psi on light oils with AC coils, in 1/8", 1/4" and 3/8" with a 3/16" port.
Standard Velvetrol® pilot-operated valves must be installed in a horizontal line with the coil upright and on top. For vertical mounting, order the -76 spring-loaded pilot option; limitations apply and Gould asks that you consult the factory. Mounting orientation is a common cause of nuisance failures, so confirm it before installation at 800-634-6853.
The bronze M-1 series is built for steam, hot water, hot air and hot light oils in 1/8" to 2" NPT at 5–125 psi, rated to 365°F with Class H coils. The bronze Q-1 series covers 1/8" to 3" at 5–400 psi to 450°F and handles steam to 200 psi. On the M-1, ethylene propylene (-3EP) seat models are limited to 5–50 psi and 298°F.
Cv is the volume of fluid that will flow through the valve wide open at a given pressure drop — measured in GPM for liquids, SCFH for gases and pounds per hour for steam. Pressure drop is inlet pressure minus back pressure. Gould publishes Cv values by series and pipe size along with a Cv calculator, so you size from required flow and available drop rather than from line size.
Gould Solenoid Valves provides high-performance, AIS (American Iron and Steel) Compliant, BABA (Build America, Buy America Act) Compliant, American-made two-way solenoid valves designed for process engineers, facility managers, and industrial maintenance teams. Whether you need rapid delivery for an emergency replacement or a custom solution for a new system, our team is here to help. Contact us today.
